Impact
Weighted head released onto the face of a mounted assembly.
Qualifies the lamination bond, not the glass. A cell that delaminates under shock was bonded wrong.
OLEDLCDShenzhen
LCD and OLED display assemblies for the global replacement market, built to the original specification.
Shenzhen Risgoo Technology runs eighteen automated stations and inspects every unit 78 times before it ships. The company holds 170 product patents and publishes a film library covering the full production process.
The position
RISGOO builds every display to the panel maker's original specification.
A replacement display is normally where cost comes out. A looser panel bin, a thinner adhesive, a driver qualified at a lower refresh rate. The part fits, powers up, and is visibly not the one that came out.
RISGOO buys cells from the same four panel makers that supply the handset industry, bonds them with Mitsubishi optically clear adhesive on an eighteen-station automated line, and measures every finished unit 78 times before it ships.
Panels supplied by
BOE · Tianma · JDI · AUO
1000+
Screen assembly SKUs ·
170+
Product patents
200+
Global trademark registrations
30+
Research engineers
300+
Operations team
10,000m²
Floor space
Figures marked · are published by RISGOO without a supporting list. They are reproduced as claims, not as counts held on file.
The specification
Four specifications every unit is measured against.
Published on every pack and on the specification page of the brand book. Every material and process on the line is chosen to meet these four numbers.
500nit
Brightness
Held across the sheet, not peaked at centre. Uniformity is a backlight-assembly problem before it is a panel one.
120Hz
Refresh rate
Driver and bonding qualified to the same rate as the handsets these replace.
99.99%
NTSC coverage
Colour calibrated per programme rather than per batch, which is what makes unit-to-unit drift measurable.
35%
Heat dissipation
Improvement from a graphene layer, against RISGOO's own previous construction.
Colour accuracy is checked against a reference panel.
A single panel viewed on its own always looks correct, so RISGOO ships a dual-screen comparison box to its distributors and runs an eight-unit linkage rig on the line. Both exist to show that colour holds steady from one unit to the next, not just within one unit.
The test rigsConstruction
Seven layers, four of them specified by supplier.
Each layer below is listed with the parts the brand book specifies by supplier. RISGOO publishes the full stack.
- 01
Cover plate
New custom cover CG · CG bracket
- 02
Support
- 03
OCA
Mitsubishi OCA · Backlit intensifier
- 04
IPS sheet on glass
Original colour anti-static tablet · Custom glitter IPS
- 05
Glass
Regulation glass + FPC
- 06
Under-glass glitter enhancement
- 07
Backlight
Production
Eighteen stations, glass loading to FPC bend.
Fully automatic ACF attachment, COF/COG bonding and AOI particle detection. The stations set in orange are the ones the factory flags as determining yield.
01
Glass loading
02
ITO plasma
03
ACF attachment
Fully automatic
04
IC CCD preloading
05
COF/COG bonding
Fully automatic
06
AOI
FOG binding particle detection
07
3-in-1 dispensing
Ag, face glue, wire glue
08
FOG electrical measurement
09
CG inspection
10
OCA tear film
11
Cover plate prepressure fit
With FOG
12
Assy OCA defoaming
13
Visual inspection
With UV curing
14
Glass loading
15
Backlight coating
16
Backlight fit
17
Backlight solder
18
FPC bend
Validation
The factory films its own destructive testing.
Six rigs, all recorded on film. RISGOO is the only supplier in the category that publishes footage of its own destructive testing, not just a written result.
Immersion
Powered assemblies held submerged in a clear tank.
Tests the adhesive perimeter as a sealed system. It is the hardest thing to get right at volume and the first thing a cheap line drops.
Flex
Flexible panel driven around a fixed radius, cycled.
Qualifies the FPC tail and the bend station that forms it - station 18, and the last chance to ruin a finished unit.
Point load
An industrial sewing machine run across the cover glass.
Concentrated load at a repetition rate no drop test reaches. It characterises the cover glass and the OCA together.
Electrostatic discharge
Discharge applied directly to a powered assembly.
ESD is the dominant field-failure mode in this category. Surviving it is a function of the anti-static layer specified at stack position four.
Eight-unit linkage
Eight assemblies driven from a single source, side by side.
The only honest test of unit-to-unit consistency. Colour drift between units is invisible one at a time and obvious in a row of eight.
Governance
ISO 9001:2015
IAF Quality Management System
CCIC
China Inspection Certification Company
The range
Two display programmes: LCD and OLED.
The difference between the two lines is the panel technology, not a trim level. Neither is a lower grade of the other.
LCD
Highlight Screen
The volume programme, and the line the brand is named for. An IPS cell on a custom cover glass, bonded with Mitsubishi optically clear adhesive, with the backlight stack tuned to hold 500 nit evenly across the panel rather than peak at the centre. Most of RISGOO's SKU range runs on this line.
- Colour coverage
- ≥13million
- Brightness
- 500nit
- Resolution
- 1080P
OLED
OLED Screen
The higher-margin programme, for handsets that originally shipped with an emissive panel and cannot take an LCD replacement without a visible colour shift. It has a wider colour gamut than the LCD line and holds colour to 178 degrees off-axis.
- Colour coverage
- ≥16million
- Viewing angle
- 178°
- Refresh rate
- 120Hz
Unit economics
37g
Saves 50% of shipping cost
A drawn steel tin replacing a moulded tray in a carton. It protects the assembly identically and weighs a fraction of it. On a category where freight is a material share of landed cost, halving it is a margin decision taken at the packaging line.
Ten assemblies per box, 180 per carton.
Iron box
37 g. Ten assemblies per box, 180 per carton.
Vacuum bag
Sealed in line, so the assembly leaves the factory without an electrostatic path into it.
Repair kit
Cleaning wipe, disassembly card, dust-free tape and service card, boxed with every unit.
Footprint
Ten thousand square metres, two commercial floors, ninety countries.
Operations centre
ShenzhenEleventh floor of Building 3, Honghu Technology Park. Brand operations, commercial, and the room distribution agreements are signed in. A twelfth floor went into construction in 2025.
Branch
GuangzhouOpened March 2026, built to the same specification as Shenzhen. Replicable fit-out is what makes a distribution network a network rather than a list of accounts.
Production
ShenzhenEighteen stations from glass loading to FPC bend, across ten thousand square metres, with upstream panel supply from BOE, Tianma, JDI and AUO.
Continuous innovation, creating a boundless future.
The brand books, the specification, the full film library and the price list are all available on request.
